ZNC EDM (AC Servo) Electrical Discharge Machine with 500x300 MM Worktable and 450 KG Max Workpiece Weight
₹ 9,50,000
New Delhi
TrustSEAL
TrustSEAL
TrustSEAL1/4
- Worktable size
- 500x300 MM
- Max workpiece weight
- 450 KG
- Brand
- JK Machines
- Model Name/Number
- 35S
- Weight
- 1300
- Machine Type
- AC SERVO
- Location
- Pan India
- Payment Mode
- Online
- I Deal in
- New Only
- Country of Origin
- Made in India
- Delivery Time
- 4 TO 6 WEEKS
- Product Brochure
- 15" LCD color display
- Programmable Z axis
- 50 step, 100 program storage
- Mirror finishing special circuit (Optional)
- Built in 3 axis DRO resolution 1 micron
- Precision co-ordinate table on flat & V type turcide coated guide ways driven by ball screw
- Double door large work tank for ease of loading & unloading of workpiece
- Oil level alarm, Oil temrature alarm
- Highly accurate work head with the quill running on preloaded cross roller bearing and ball screw
- High speed quill moment with Panasonic AC servo motor
- Attractive compact looks
- Hand held multi function remote control
- Z axis lock function
- Mm and Inch display
- Reverse servo machining
- Safe & stable, No arc machining
- Like to like material machining
- Calibrated EDM technology
- Automatic lubrication system
- Fire extinguisher, Smoke detector alarm
- Self diagnostic trouble shooting with alarm
- Sleep mode, Auto mode
- Efficient dielectric system with double filteration
- Axis Corrector
- Flat Electrode Holder
- Round Electrode Chuck
- Flushing Aids
- Clamping Kit
- Mounting/Leveling Pads
- Tool Kit
- Servo stabilizer
- Edm oil
- Orbital attachment
- Translatory head
- Magnetic chuck
